USE:
It is specifically designed for the water glue. It can first coat glue on the rubber film and then it will be dried through a warm water pulley.
It can stick the glued film onto the paper surface by heating or pressurizing under the warm water pulley. The large-sized warm water pulley of 800m in diameter adopted warm water circulation system. It can heat fast stably and correctly. This machine is specifically designed for the chain-type cutter system. It is applicable for all kinds of films. It can automatically slit and deliver the film. The machine specially designed for water gel film laminator can reduce the emission of dimethylbenzene and exhaust. As a result it is well accepted in the well developed countries.

Standard Equipment
  Automatic paper feeder
  Glue Coating holder, drying channel, sticker
  Disc and chain type paper cutter
  Automatic paper delivery(Optional)
  Warm water heating system
Optional Equipment
.Single-holder dust remover
.Double- holder dust remover
.Air compressor

.Electrostatic Treatment Device

Main technical variables
Model	QLDM-1100
Speed	20-60m/min
Using Paper	100-500g
Max Using Size	1000×1050mm
Min Using Size	285×350mm
Total quantity of power consumption	68kw
Overall Dimensions	9600×2200×2600mm
Total Weight	8800kg
