Asphalt Coated Woven Glass Fabric 10x20,20x20
Fiberglass mesh cloth is on the basis of fiberglass woven fabric,then coatedby acrylic acid copolymer liquid. Therefore, It has good alkaline-resistance, high strength, excellent alkali and acid resistance,
good cohesion, excellent in coating etc. can be widely used in building internal and external wall insulation, waterproof, crack resistance and so on.
Application:
1. Wall reinforcement materials (such as fiberglass wall mesh , GRC wallboard,EPS in and outer wall insulation board, gypsum board,etc)
2. Strengthening cement products ( Roman columns,flue)
3. Granite,mosaic special mesh, marble back mesh
4. Waterproof roll cloth and asphalt roof waterproof
5. Reinforced the skeleton materials of plastic and rubber products
6. Fire board
7. Grinding wheel base fabric
8. Caulking belts for construction
|
Product Code |
Yarn Tex (Tex) |
Density (Counts/25mm) |
Treated Unit Wt |
Tensile Strength(N/5cm×20cm) |
|||
|
|
Warp |
Weft |
Warp |
Weft |
G/m2 |
Warp |
Weft |
|
RD45-8×8 |
30×2 |
45 |
8 |
8 |
45 |
≧420 |
≧420 |
|
RD60-10×20 |
30×1 |
67 |
10 |
20 |
60 |
≧450 |
≧450 |
|
RD80-5×5 |
67×2 |
200 |
5 |
5 |
80 |
≧700 |
≧850 |
|
RD80-20x20 |
38x1 |
67 |
20 |
20 |
80 |
≧450 |
≧450 |
|
RD110-10×10 |
250×2 |
400 |
2.5 |
2.5 |
110 |
≧1250 |
≧1250 |
|
RD125-5×5 |
134×2 |
250 |
5 |
5 |
125 |
≧750 |
≧1000 |
|
RD135-5×5 |
134×2 |
300 |
5 |
5 |
135 |
≧1300 |
≧1400 |
|
RD145-5×5 |
134×2 |
350 |
5 |
5 |
145 |
≧1250 |
≧1700 |
|
RD160-4×4 |
134×2 |
300 |
6 |
6 |
160 |
≧1550 |
≧1600 |
|
RD165-4×5 |
134×2 |
350 |
6 |
5 |
165 |
≧1300 |
≧1300 |
|
RD300-4×5 |
200×2 |
700 |
6 |
5 |
300 |
≧2000 |
≧3000 |
